Docan R5200 Printer
R5200, inheriting DOCAN’s premium manufacturing, features an integrated welded structure for superior rigidity and high-speed stability. Equipped with 4-row Konica printheads, it effortlessly achieves 124sqm/h high-speed UV printing.
Optimized for extra-wide material processing to minimize splicing and material waste.Increased single-pass printing area, covering wider materials for enhanced compatibility.Significantly improved production efficiency, supporting up to 4 rows of Konica printheads for high-output performance
Functions
- Material flattening: Dual-roller system eliminates wrinkles for precise printing alignment.
- Tension stability: Maintains consistent material tension to prevent slippage during continuous printing.
- Print quality enhancement: Stabilizes nozzle-to-media distance for accurate ink.
- droplet placement.
- Regulates heat buildup between material and printhead to prevent thermal deformation and maintain material flatness.
- Ensures stable ink curing: Temperature control minimizes heat interference for precise droplet placement and uniform curing.
- High-efficiency water cooling supports high-capacity production and continuous high-speed operation.
Specifications
| Specification | Details |
|---|---|
| Curing Method | UV LED |
| File Formats | TIFF, JPEG, EPS, PDF |
| RIP Software | SAI / ONYX / Caldera |
| Power Requirements | AC220V 50/60Hz 10KW 45A |
| Environment | Temperature: 20°C–28°C, Humidity: 40%–60% |
| Ink Tank Capacity | 5L |
| Dimensions | 8150mm × 2000mm × 1950mm |
| Weight | 6435kg |
